8-Inch 2-Way Active Studio Monitors With EBM Waveguide
With a smooth, accurate frequency response; powerful amplification with tons of headroom; and Acoustic Tuning functions that ensure you get the best sound, it’s no wonder that Eris®-series studio monitors have been a runaway hit since their introduction. Building on the reputation of its award-winning predecessors, the Eris Studio 8 is a substantial update that delivers richer low-end and more controlled high-frequency response, reproducing every detail in your recordings with a natural sound unparalleled in its class.
Designed for superior performance in both home studios and professional mix rooms, the Eris Studio 8 features a custom-designed EBM (Elliptical Boundary Modeled) waveguide that provides superior high-frequency response and wide 120-degree horizontal dispersion to create a broader sweet spot. Narrow vertical dispersion reduces reflections from your desk, and a 1.25-inch, silk-dome tweeter ensures snappy, accurate transient reproduction. An elegant new enclosure design improves the waveguide performance so you’ll hear the finest details in your mix.
The woven-composite, 8-inch, low-frequency driver offers Eris’ signature tight, clear bass with plenty of punch. Its 140W of biamped power make the Eris Studio 8 more efficient than previous designs. The ported enclosure maximizes bass response and allows the Eris Studio 8 to reach down to an astonishing 35Hz – with no subwoofer!
Flexible input options let you connect almost any line-level source, from mixers to audio interfaces and more. You’ll have no problem hooking your Eris speakers up to virtually anything.
Features:
- 8-inch woven composite, low-frequency transducer
- 1.25-inch (31.75mm), ultra-low-mass, silk-dome, high-frequency transducer
- 120˚(H) x 60˚(V) EBM waveguide for a wide sweet spot
- Front-firing acoustic port for superior bass-frequency reproduction and optimized, resonance-suppressing internal bracing
- 140W, Class AB biamplification
- 35Hz to 20kHz frequency response
- 106dB SPL (Peak, @ 1meter)
- Acoustic Tuning controls: HF (±6dB, continuously variable); Midrange (±6dB, continuously variable), and Acoustic Space (flat, -2, -4dB), plus highpass filter (Off, 80Hz, 100Hz)
- RF interference, output-current limiting, over-temperature, transient, subsonic protection, and amplifier “soft start” feature (eliminates popping on power-up)
- Internal power supply with IEC connector and power switch with on/off LED
- Balanced XLR and ¼-inch inputs and unbalanced RCA inputs
Highlights & Specs:
Set Up Your Studio Monitors For Your Room.
Eris® Studio 8 active monitors are equipped with Acoustic Tuning controls to ensure the flattest response in your mix environment. You get Low Cut, Mid, and High controls, as well as three-way Acoustic Space tuning that makes it easy to compensate for the boundary bass boost that occurs when a speaker is placed too close to a wall.
Honest. Expressive. Powerful.
Like all PreSonus® studio monitors, the Eris® Studio 8 offers consistent, accurate listening. Their stylish design makes them a welcome addition to any mix space, and their smooth, incredibly even frequency response ensures that your mixes will sound great everywhere.
Electronics:
- Voltage Requirements100-240 VAC, 50-60 Hz
- Connection TypeIEC
Hardware:
- Cabinet MaterialVinyl-Laminated, Medium-Density Fiberboard
Measurements:
- Width9.84″ (25 cm)
- Height16.5″ (41.91 cm)
- Depth11.73″ (29.8 cm)
- Weight22.2 lbs. (10.07 kg)
Monitors:
- ProtectionsRF interference
Output-current limiting
Over-temperature
Turn-on/off transient
Subsonic filter - Audio SwitchesAcoustic Space (Flat, -2 dB, -4 dB)Low Cut (Flat, 80 Hz, 100 Hz @ -12 dB / octave)
- Audio ControlsVolumeHigh Frequency (±6 dB, center 10 kHz, continuously variable)Mid Frequency (±6 dB, center 1 kHz, continuously variable)
- Peak SPL106 dB (@ 1 meter)
- Crossover Frequency3.5 kHz
- Monitor Inputs1- Balanced XLR, 1- Balanced ¼” TRS, 1- Unbalanced RCA
- HF Transducers1.25” Ultra Low Mass, Silk Dome Tweeter
- LF Transducers8″ Woven Glass Fiber Composite
- Frequency Response35 Hz – 20 kHz
- Input Impedance10 kΩ
- Coverage Pattern120 degree (H) x 60 degree (V)
- Monitor Amplifier PowerLF Amplifier – 75W, HF Amplifier – 65W
